Hey. Can someone please confirm spoke length needs please.

Mavic 217 Sup Rims.

Shimano XTR M950 Hubs

32 hole

Thanks in advance

If you get no luck. There’s a wheel building group on fb who are very helpful.
Bicycle wheel building group

217 sunsets on standard shimano hub was 262mm front 3x. Erd 540

Cant give you a rear as it was a specially spaced hub. But you can probably now work that out...


Attachments

  • 17138914145425120396304820154039.jpg
    296.1 KB · Views: 9
That is a very good resource. I have used it lots of times and spoke lengths have always been spot on.
